Miscellaneous Equipment
6 & 8 Digit Subsea Display
The 6 & 8 Digit Subsea Display is a standalone product for showcasing information from subsea equipment.
The Display can be connected to battery pack and external smart sensors, making a complete standalone monitoring system.
An ambient light sensor is integrated into the display. This can be used to wake the display from sleep by light from an ROV. An adjustable timeout will turn the Display off when no light is present. -
Miscellaneous Equipment
Digital CP Probe System
The iCsys Digital CP System connects to standard CP sensors and converts the analog signal locally to a digital RS232 or CANBus communication.
This solution minimizes noise and interference to the signal because of the short analog signal path. It simplifies integration into existing systems by eliminating the need for specialized CP sensor inputs. A windows based graphical user interface application displays the readings and also displays a one minute history on a graph. It is possible to log the reading and add notes to be able to print or archive the readings for later lookup.
-
Miscellaneous Equipment
Pressure Relief Valve
A compact, highly accurate, direct acting pressure relief valve. Factory preset to 0.8 Bar or 1,5 Bar crack pressure. Internal adsjustments provides tamper proof safety against inadvent pressure changes.
PRV 1/4’’ BSP – 0,8 Bar Crack Pressure
PRV 1/4’’ BSP – 1,5 Bar Crack Pressure
PRV 1/2’’ BSP – 0,8 Bar Crack Pressure
PRV 1/2’’ BSP – 1,5 Bar Crack Pressure -
Miscellaneous Equipment
Seanet Junction Box
The Seanet Junction Box is used to make it simple and easy to use as an interface from Glenair Cables to Seanet Cables.
With a Glenair G5506-2008 male connector in one end and Seanet Connector in the other end.
Designed with the see-through glass to easily check the wiring inside.
-
Miscellaneous Equipment
Subsea Battery Canister
The subsea battery canister is a standalone product for power storage and distribution.
The canister is the same size as other standard Ixys tubes, thus making it easy to fit in existing designs.
Easy hook-up and activated with an included switch plug.
A simple 12A charger is included.
-
Miscellaneous Equipment
Subsea Flowmeter 0,5-25 LPM
Our Subsea Flow Meters are available in a wide variety of flow ranges and electrical outputs, as well as a variety of exotic materials for highest corrosion resistance and material compatibility. Electronics are integrated and sealed to withstand external pressures and temperatures.
Gear Flow Meters are positive displacement meters, similar in design to a gear pump. The measuring medium rotates two gears, which are engaged with minimum play. The medium is forced along through closed measuring chambers between gears and housing. The gears, which run idle, lose no power in the medium stream. The rotational speed is proportional to the flow and is tapped from pickups from the housing wall.
-
Miscellaneous Equipment
Subsea Flowmeter 15-150 LPM
The ETL range of subsea flowmeter, all stainless threaded. Flowmeter allows measurement between 15 and 150 L/min.
Our subsea flowmeters are available in a wide variety of flow and pressure ranges. Flowmeters comes with 1.1/4’’ BSP female threads as standard but can be configured on client requirements. Max working pressure on flowmeter is 690 Bar. Flowmeter is turbin style. Laptop with user-friendly software for monitoring and logging of low is included in kit.
-
Miscellaneous Equipment
Subsea Load Monitor
The SLM has a maximum working depth of 500m and a magnetic trigger for reed switch operation. The readability is 1kg. 7- segment LED monitor.
The refresh rate is 16MHz. With the SLM you have approx. 500 hours of operation.
-
Miscellaneous Equipment
Surface Mincord Inspection Camera
Small and compact: The Mincord camera are designed to reach even the most difficult-to-reach places.
The non-destructively inspection enables you to inspect even the tightest spaces and saving costly disassembles. Tubes, cavities, welding seams, turbines, hollow profiles and castings: The camera head with only 13mm diameter inspects these easily. At the same time, the cameras are so robust that they can easily withstand the harsh field conditions. In this way you locate all surface damages, cracks, sediments and deteriorations with minimal effort.
