The 4-Station High Flow Valve Pack is an universal remotely operated control unit which consists of 4 x directional control valves with individual pressure and flow control, allowing high flow of up to 120l/min in the output lines.

The valve pack use our well known and proven PCB board to operate the hydraulic control valves which give pilot pressure to each PVG valve to control flow and pressure. Each valve group has pressure sensors for monitoring input- and output pressure. Auxiliary signal input is also achieved through a dedicated connector.

Compact and user friendly pilot operated proportinal directional control valve mounted on a aluminium steel plate.

This valve is a 4-way, 3-position proportional directional valve. Work ports 2 and 4 are drained to 5 in the center position and port 3 is closed. Pilot pressure at port 1 opposes the spring and creates a variable metering orifice between ports 3 and 4 that is proportional to the pressure at 1. Piloting 6 opens 3 to 2. The force balance of the flow forces, spring and pilot pressure results in a degree of partial self-compensation as the load pressure changes.

Modular Valve Pack system based on ingelligent firmware, specially designed to handle different hydraulic control requirements for both simple and complex underwater system and tooling applications.

The 4-function Modular Valve Pack is designed with purpose of being a low cost valve pack, with all features needed to operatesubsea tooling. The design is compact and user-friendly ”plug and play” of valve modules. The 4-function Valve Pack can easily be increased with additional valve modules as extension to existing setup.
